Description:

This notebook demonstrates the generation and aggregation from one polygon source to another polygon target. The example here demonstrates mapping USGS National Hydrologic Model output to CONUS HUC12s. Calculation of area weighted statistics as shown here is useful process in many water budget or landscape analysis applications.

Additional Information:

This notebook demonstrates the generation and aggregation from one polygon source to another polygon target. The example here demonstrates mapping USGS National Hydrologic Model output to CONUS HUC12s. Calculation of area weighted statistics as shown here is useful process in many water budget or landscape analysis applications.

Why

In the use-case presented here we are interpolating hydrologic modeling results of soil moisture, calculated on a unique spatial fabric of polygons representing Hydrologic Response Units (HRU) which are often represented as polygons splitting a catchment on either side of the stream network of that catchment to a more common fabric such as 12 digit hydrologic unit codes (HUC12). It could be other polygons for example representing states or counties. To interpolate the values, a weights table is calculated which describes the fraction of each contributing HRU to the HUC12. The interpolation is this case is the sum of soil moisture values for each HRU multiplied by the weight for that HRU/HUC12 combination as represented in the weights file. This kind of interpolation is common in hydrologic sciences and this demonstration can be used as a template for other interpolations.

Open source python tools

• gdptools: GeoDataProcessing Tools (GDPTools) is a python package for geospatial interpolation
• Geopandas: Geopandas is a python package for geospatial dataframes.

Data

• conda/mamba environment file ‘environment.yml’ https://www.sciencebase.gov/catalog/item/64cbcc52d34e2d58db2fa44b.
• Source Geometry: GFv1.1.gdb.zip available via sciencebase https://www.sciencebase.gov/catalog/item/5e29d1a0e4b0a79317cf7f63. https://doi.org/10.5066/P971JAGF
• Source Data: nhm_sm_subset.nc A 1-month subset of NHM ouput for the period 2020-01-01 - 2020-01-31. This dataset if for demonstration purposes only. It containts the output for Total soil-zone water storage. https://www.sciencebase.gov/catalog/item/64cbcc52d34e2d58db2fa44b
• Target Data: WBD_National_GDB.gdb available via sciencebase https://www.sciencebase.gov/catalog/item/63cb38b2d34e06fef14f40ad at the link https://prod-is-usgs-sb-prod-publish.s3.amazonaws.com/63cb38b2d34e06fef14f40ad/WBD_National_GDB.zip. https://doi.org/10.5066/P92U7ZUT

Description

In this use-case we interpolate the Total Soil Moisture output from the National Hydrologic Model (NHM) for a period of 1-month between 2020-01-01 and 2020-01-31 to CONUS twelve digit hydrologic unit code (HUC12). The following steps are performed. The Geometry data for both the NHM Hydrologic Response Units (HRUs) and the twelve HUC12 are read into a Geopandas Dataframe. The NHM ouput file is read into an XArray dataframe. GDPTools is used to create an area-weighted mapping between the source geometry (HRUs) and the target geometry (HUC12s). Then using the weights file the NHM results are interpolated to HUC12s. This demonstrates a common use-case for spatial interpolation from one geometry to another.

Imports

import os
import warnings
import time
os.environ['USE_PYGEOS'] = '0'  # Force use of shapely>2.0
# Data containers
import geopandas as gpd
import numpy as np
import pandas as pd
import xarray as xr

# Plotting
import hvplot.pandas
import hvplot.dask
import holoviews as hv
from holoviews.element.tiles import EsriTerrain

# GDPTools
from gdptools import WeightGen
from gdptools import AggGen
from gdptools import UserCatData

warnings.filterwarnings('ignore')
hv.extension('bokeh')

calc_weights = True

Download and read data

The source fabric (GFv1.1.gdb), target fabric (WBD_National_GDP), and the source data (nhm_sm_subset.nc) using GeoPandas for the fabrics and XArray for the data. Adjust the paths to the data as necessary.

# Source data
source_fabric = '~/data/GFv1.1.gdb'
source_data = '~/data/nhm_sm_subset.nc'

# Target data
target_fabric = '~/data/WBD_National_GDB/WBD_National_GDB.gdb'

# Read data
start = time.time()
source_gdf = gpd.read_file(source_fabric, layer='nhru_v1_1_simp')
source_fabric_time = time.time() - start
print(f"Source fabric read in: {source_fabric_time} seconds")

start = time.time()
source_ds = xr.open_dataset(source_data)
source_data_time = time.time() - start
print(f"Source data read in: {source_data_time} seconds")

start = time.time()
target_gdf = gpd.read_file(target_fabric, layer = 'WBDHU12')
target_fabric_time = time.time() - start
print(f"Target fabric read in: {target_fabric_time} seconds")

Source fabric read in: 22.118669986724854 seconds
Source data read in: 3.0059561729431152 seconds
Target fabric read in: 121.06751918792725 seconds

Look at the structure of each data source

source_gdf.head()

source_ds

<xarray.Dataset> Size: 15MB
Dimensions:         (nhru: 114958, time: 31)
Coordinates:
  * nhru            (nhru) int32 460kB 1 2 3 4 5 ... 114955 114956 114957 114958
  * time            (time) datetime64[ns] 248B 2020-01-01 ... 2020-01-31
Data variables:
    nhm_id          (nhru) int32 460kB ...
    soil_moist_tot  (time, nhru) float32 14MB ...
Attributes:
    history:  Tue Jan 17 19:24:30 2023: ncks -O -4 -L 2 --cnk_map=dmn --cnk_d...
    NCO:      netCDF Operators version 5.1.0 (Homepage = http://nco.sf.net, C...

target_gdf.head()

Simply GeoDataFrame

Generally it’s a good practice to reduce the source geometry to include only the required columns, which are in this case are the feature id used to key the geometry and the geometry itself. Here, the identifiers are ‘nhru_v1_1’ and ‘geometry’ respectively. Simplifying in this way reduces the overall memory footprint when calculating the weights and interpolating the source data to the target fabric.

source_gdf_simp = source_gdf[['nhru_v1_1', 'geometry']]
source_gdf_simp.head()

Filter HUC12s to those that are within CONUS only and eliminate the Lake Michigan HUC12.

Here we filter HUC12s to represent the land-based HUC12s for CONUS only.

filter_water = ['Lake Michigan']
filter_state = ['MX', 'CN']
filter_huc12 = ['19', '20', '21', '22'] # Alaska, Hawaii, Puerto Rico, Pacific Islands

# Fileter non-conus HUC12s using filter_huc12
print(f"Number of huc12s before filtering: {len(target_gdf)}")
wbd_conus = target_gdf[~target_gdf['HUC12'].apply(lambda x: any(x.startswith(prefix) for prefix in filter_huc12))].copy()
print(f"Number of huc12s after filtering non-conus huc12s: {len(wbd_conus)}")

# Filter polygon representing Lake Michigan
wbd_filt = wbd_conus[~wbd_conus['NAME'].isin(filter_water)].copy()
print(f"Number of huc12s after filtering type: {len(wbd_filt)}")

# Filter polygons that are in Mexico and Canada
wbd_filt1 = wbd_filt[~wbd_filt['STATES'].isin(filter_state)].copy()
print(f"Number of huc12s after filtering states: {len(wbd_filt1)}")

# Filter partial polygons in Mexico and Canada
wbd_filt2 = wbd_filt1[~(wbd_filt1['STATES'].str.contains('CN'))].copy()
print(f"Number of huc12s after filtering Partial Canadian hucs: {len(wbd_filt2)}")
wbd_conus = wbd_filt2[~(wbd_filt2['STATES'].str.contains('MX'))].copy()
print(f"Number of huc12s after filtering Partial Mexican hucs: {len(wbd_conus)}")

Number of huc12s before filtering: 101725
Number of huc12s after filtering non-conus huc12s: 86735
Number of huc12s after filtering type: 86734
Number of huc12s after filtering states: 83323
Number of huc12s after filtering Partial Canadian hucs: 82828
Number of huc12s after filtering Partial Mexican hucs: 82547

wbd_conus.head()

# Print columns. Note we use HUC12 as our feature id.
wbd_conus.columns

Index(['TNMID', 'METASOURCEID', 'SOURCEDATADESC', 'SOURCEORIGINATOR',
       'SOURCEFEATUREID', 'LOADDATE', 'GNIS_ID', 'AREAACRES', 'AREASQKM',
       'STATES', 'HUC12', 'NAME', 'HUTYPE', 'HUMOD', 'TOHUC',
       'NONCONTRIBUTINGAREAACRES', 'NONCONTRIBUTINGAREASQKM', 'GLOBALID',
       'SHAPE_Length', 'SHAPE_Area', 'geometry'],
      dtype='object')

Simply target GeoDataFrame

As discussed with the source GeoDataFrame, here the target GeoDataFrame is simplified to the ‘HUC12’ feature id and ‘geometry’

wbd_conus_simp = wbd_conus[['HUC12', 'geometry']]
wbd_conus_simp.head()

Generate weights for interpolating between the target and source polygons.

Here we use GDPTools ParallelWghtGenEngin class. Depending on the resources available one could also use the SerialWhgtGenEngin or DaskWghtGenEngine. This notebook was developed using a computer with 16 processors. A good rule of thumb is to use half the available processors.

from gdptools.weights.calc_weight_engines import ParallelWghtGenEngine
if calc_weights:
    wght_gen = ParallelWghtGenEngine()
    weights = wght_gen.calc_weights(
        target_poly=wbd_conus_simp,
        target_poly_idx="HUC12",
        source_poly=source_gdf_simp,
        source_poly_idx=["nhru_v1_1"],
        source_type="poly",
        wght_gen_crs=6931,
        filename='nhm-to-huc12-weights.csv',
        jobs=8
    )
else:
    weights = pd.read_csv('nhm-t0-huc12-weights.csv')

Reprojecting to epsg:EPSG:6931 finished in 60.34 second(s)
Validating polygons
     - validating source polygons
     - fixing 9991 invalid polygons.
     - validating target polygons
     - fixing 1 invalid polygons.
Validate polygons finished in 13.9189 seconds
Weight gen finished in 167.9950 seconds

Aggregate NHM Total Soil Moisture results to HUC12s

Start by grouping the weights by HUC12s, as the interpolation between the source data and the HUC12s will be calculated by HUC12.

# group weights by HUC12 id
weights_huc12 = weights.groupby('HUC12', axis=0)

# Example of HUC12 weights for a given HUC12 id
weights_huc12.get_group('010100020101')

The HUC12 weights for the given HUC12 id shows that 6 HRUs intersect the HUC12 and the wght column indicates the fraction of the HUC12 area intersected by the hru id (nhru_v1_1)

Loop through HUC12s and apply weights to interpolate the NHM results

The source NHM data is interpolated to the target HUC12 polygons by iterating over the weights which have been grouped by the ‘HUC12’ and calculating the interpolated value as the sum of the hru valus*weights by using the dot product.

# The name of the NHM variable - see xarray.Dataset representation above.
key='soil_moist_tot'

# Create array to hold the interpolated data dimensioned by (time, HUC12)
agg_values = np.zeros((len(source_ds.time), len(wbd_conus)))

for index, group in enumerate(wbd_conus.HUC12.values):
    if index % 10000 == 0:
        print(index, group)
    try:
        weight_table = weights_huc12.get_group(group)
        # weight values
        w_vals = weight_table['wght'].values
        hru_ids = weight_table['nhru_v1_1'].values.astype(int)
        hru_vals = source_ds[key].sel(nhru=hru_ids).values

        # Use dot product of the values and weights to calculate the interpolated
        # value
        agg_values[:, index] = hru_vals.dot(w_vals.T)
    except KeyError as error: # This catches HUC12s that have no weights.
        agg_values[:, index] = np.nan

0 031401030101
10000 101900031206
20000 031300110502
30000 102901060405
40000 150100150401
50000 110902040502
60000 120800060602
70000 171003020707
80000 080302090601

Create a plot of Total Soil Moisture for the 2020-01-30

Here we use spatialpandas and hvplot. Because the number of polygons is large we get a performance boost using spatialpandas.

import spatialpandas as sp
import spatialpandas.geometry
import spatialpandas.dask
from spatialpandas import GeoDataFrame

wbd_conus['TotSoilMoist'] = agg_values[30,:]
sp_wbd = GeoDataFrame(wbd_conus)
sp_wbd.hvplot(c='TotSoilMoist', rasterize=True, colorbar=True, hover=True, hover_cols=['TotSoilMoist'], clim=(0,5), tiles=hv.element.tiles.EsriTerrain, title="Total Soil Moisture (inches)")

Summary

This use-case shows how to interpolate hydrologic modeling results of soil moisture from spatial units specific to model (hydrologic response units or HRUs) to other spatial units such as more standard hydrologic units (Watershed Boundary Dataset HUC12s in this case). The same process could be used for other polygon areas like counties. To interpolate values from one set of polygons to another, a table of intersection weights containing the fraction of each contributing HRU to overlapping HUC12s is calculated. The interpolation is then calculated as the sum of soil moisture values for each HRU multiplied by the weight for that HRU/HUC12 combination as contained in the weights file. This kind of interpolation is common in hydrologic sciences and this demonstration can be used as a template for other interpolations.
